Zhixing Machine
Zhixing Machine
CNC Machining Centres for drilling milling tapping thread of aluminum profile/ copper profiles/ steel profiles
Model: DSK-CNC-3000DK
Tailored for aluminum profile batch production. Spindle speed range of 12,000-24,000 rpm achieves 30%-50% faster cutting speeds than conventional centers. Combines milling, drilling, boring, tapping, and chamfering in one setup.
Utilizes ball screw + linear guide structure, achieving positioning accuracy of ±0.01mm and repeatability of ±0.005mm. Built-in temperature sensors enable real-time thermal deformation compensation.
Anti-sticking design with high-pressure cutting fluid spray prevents aluminum chips from adhering to tools. Large X-axis travel (up to 6000mm) supports integral machining of long architectural curtain wall frames.
| Category | Typical Range | Description |
|---|---|---|
| Spindle System | 12000-24000 rpm | High speeds for efficiency; BT30/BT40 taper options |
| Spindle Power | 7.5-30 kW | Higher power for harder alloys like 6061 or 7075 |
| Travel (X-Axis) | 2000-6000mm | Determines maximum machinable profile length |
| Travel (Y/Z-Axis) | 300-800mm / 300-500mm | Determines machining width and depth |
| Tool Magazine | 16-48 tools | Supports complex multi-process integration |
| Tool Change Time | 1.5-3 seconds | Fast tool-to-tool transition |
| CNC System | FANUC / Siemens / Mitsubishi | Ensures stability and ease of programming |
🏙️ Construction Industry
Door/window frames, curtain wall studs, sunroom frames, and stair handrails.
🚗 Automotive Industry
Bumper brackets, engine mounts, and battery trays for new energy vehicles.
✈️ Aerospace Industry
Wing components, fasteners, and instrument panel brackets with high-strength alloys.
📱 Electronics & Appliances
Mobile phone/computer casings, heat sinks, and refrigerator door frames.
